Cognito Upper Control Arm Kit 2020 Duramax L5P UCANew
Cognito Ball Joint SM Series Upper Control Arm Kit for 2020 Chevrolet and GMC 2500HD / 3500HD 2WD/4WD trucks.
Fits as stock replacement on leveled and lifted applications where an upgrade is desired to provide better performance, style, and function. The boxed sheet metal arms are CNC robot welded and powder coated semi-gloss black. Alloy series ball joints are included as well as new crush sleeves and polyurethane bushings. Upper control arms are not meant to be a droop limiter, in the old days they were the limiter but wreaked havoc on upper ball joints. The shocks or a limit strap should be the droop limiter, and ample droop travel is required for good ride quality and all suspension components to last and work properly. This control arm kit will add performance to the Chevy and GMC truck by correcting the ball joint angle for lifted and leveled applications, increasing droop travel, and also increases caster slightly for better highway speed drivability.
Boxed sheet metal design
Bolt in style ball joint for easy replacement
Replacement ball joints available at most parts stores
Made in the USA
Must use applicable Cognito shocks to limit droop travel. Otherwise damage to the control arm, cv axle, and other parts may occur.
DHD 600-656 Heavy Duty Lower Control Arm Bracket GM Truck 01-10New
DHD 600-656 Heavy Duty Lower Control Arm Bracket GM Truck
This heavy duty lower control arm bracket was designed for pullers and drag racers. It's heavy duty tubular design is several times more rigid than the stock part it replaces. The bracket greatly reduces chassis flex that is present in the front suspension area. By installing this bracket you will be able to yield a more controllable and straighter launch on your high powered pickup.
Description: DHD Heavy Duty Lower Control Arm Bracket GM Truck
More Details »
KRYPTONITE UPPER CONTROL ARMS 110-UCAK KRUCA10 New
KRYPTONITE UPPER CONTROL ARMS 110-UCAK KRUCA10
Fits 2001-2010 Chevy/GMC 2500/3500 HD and 2002-2009 Hummer H2
Kryptonite upper control arms are laser cut and welded into an extremely strong boxed design. Made with pride here in small town USA and backed with a lifetime warranty. Kryptonite UCA kits will improve the ride of any leveled or lifted GM 2500-3500 HD truck but are also a great upgrade for your stock height truck. Kryptonite UCA's are compatible with any stock or leveled 2500-3500 HD and most suspension lift kits.
1 x Drivers side upper control arm Part# KRY-UCAK-0110-D
1 x Passenger side upper control arm Part# KRY-UCAK-0110-P
4 x Control arm sleeve Part# AP-UCA-0110
8 x Control arm Bushing Part# Q21097-BK-0110
2 x Bump Stop Part# M21097-BK
2 x XD Series Ball joints Part# XD6292
1 x Hardware package
KRYPTONITE CAM BOLT KIT
SUPERIOR TOP LOCK WITH NORD-LOCK STYLE FLANGE NUT, YOU CAN'T FIND A MORE SOLID CAM BOLT KIT ON THE MARKET. KEEP YOUR FRONT END ALIGNMENT IN CHECK WITH KRYPTONITE.
1 x Kryptonite Cam Bolt Kit Part# KRY-0026
The Kryptonite cam bolt kit is recommended to be replaced on and trucks located in a harsh climate or on any truck with high miles. The easiest time to replace the cam bolt kit is when replacing the upper control arms. The kryptonite cam bolt kit will allow for an additional -1.5º to +1.5º of additional camber adjustment.
*Cam Bolt Kit will Not Work with a control arm drop lift kit.
Description: 2001-2010 Chevy/GMC 2500/3500 HD
2002-2009 Hummer H2
Please Call for Availability
KRYPTONITE UPPER CONTROL ARMS 1115-UCAK KRUCA11New
KRYPTONITE UPPER CONTROL ARMS 1115-UCAK KRUCA11
Fits 2011-Current Chevy/GMC 2500/3500 HD
Note: When running stock wheels with oversized tires clearance is limited and may rub control arm. Please contact us prior to purchasing if running this set up.
Kryptonite upper control arms are made from laser cut billet steel. Made with pride here in small town USA and backed with a lifetime warranty. Kryptonite UCA kits will improve the ride of any leveled or lifted GM 2500-3500 HD truck. Also a great upgrade for your stock height truck. Kryptonite UCA's are compatible with any stock or leveled 2500-3500 HD and most suspension lift kits.
1 x Drivers side upper control arm Part# KRY-UCAK-1151-D
1 x Passenger side upper control arm Part# KRY-UCAK-1151-P
4 x Control arm sleeve Part# AP-UCA-1151
8 x Control arm Bushing Part# Q21097-BK-1151
2 x XD Series Ball joints
1x Hardware package
GM Cam Centric Bolts Part# 11571269
Recommended when replacing the Upper Control Arms.
