DuramaxTuner Stealth Mach 1 64 VVT Duramax Turbo Upgrade L5P 2020-2023 700HP

Calibrated power has been in the turbo and performance game for a long time. These Stealth series turbos have some of the most tested and validated components on the market. When it comes to drop in, dyno tested performance, DHD trusts Calibrated Power for your L5P.

L5P Stealth 64: Above the Rest!

• Airflow to support 700HP

  • Up to 650 RWHP with stock emissions equipment and basic supporting mods
  • Tested in competition setups with extensive supporting mods to make 700+ RWHP
  • 41 psi boost @ Sea Level
• Custom Billet Compressor Wheel

  • 11-Blade wheel provides a wide efficiency range allowing users to tow without risk of surge
  • Lightweight and high strength
  • Provides 74 lbs/min mass airflow compared to 60lbs/min stock
  • No Surge (Even when lugging)
• Oversized Custom Turbine Wheel

  • Low drive pressures at high load
  • Efficiency improved to better control EGT
  • 10 blade design produces distinctive exhaust sound
• Custom Vane/Nozzle Ring Assembly

  • Exclusive design produced in-house specific to this application
  • Taller and wider vanes match larger turbine to provide superior high-load efficiency
  • Retain factory exhaust brake and throttle response
  • Excellent EGT Control (especially during heavy load)
• Brand New parts and electronics
  • No Core Charges
  • Built from New Genuine GM/Borg units
  • Actuator is Pre-Calibrated (requires re-learn once installed in truck)
• Designed and spec'd by Tuners
  • Easy to tune (no tuning required)
  • DuramaxTuner will help your custom tuner with required settings if need be

This Turbo is Designed for you if ...

• You are running entry-level or custom tuning
• Daily drive your truck
• Have Reliability and Performance as top priorities
• Tow with your truck
• Want More Power and excellent street manners!

This turbo uses a customized nozzle ring and/or shroud plate.  It’s been engineered to provide amazing response and performance.

This turbo must only be operated with tuning that uses stock Minimum and Maximum Vane Position tables. Failure to do so can lead to excessive exhaust pressure and boost which may shorten the life of the turbo or engine and may void the turbo warranty.

Damage caused as a result of non-stock vane position tuning modifications will be the responsibility of the owner, not Calibrated Power Solutions Inc. If you have any questions or concerns please contact CPS at 815-568-7920.

 Warranty: All Stealth Series turbos offer our Unlimited Mile, 1-year manufacturer warranty for quality and craftsmanship. For warranty inquiries please contact sales@duramaxtuner.com

This Stealth L5P 64mm Turbo by Duramaxtuner.com is specifically designed for the 2017, 2018, and 2019 Chevy Silverado and GMC Sierra 2500 and 3500 models.   It replaces OEM Part #s 12709701044, 11547786, 12683985, 12689094
