SoCal Diesel Custom Ground 3388 Alternative Fire Order Keyed Duramax Camshaft

SCD3388AF - Z
Pricing: $1,199.00

Qty:
Free Shipping

Description

Alternative Firing Order Duramax Camshaft #3388AF

Extend the life of your crankshaft by changing the firing order of your engine.

The OEM firing order ends with cylinder 3 and begins with cylinders 1 and 2. The result is a 3-1-2 hit to the crankshaft. Duramax cranks have a tendency to break right behind the first rod throw at the intersection of the second main journal, right where the 3-1-2 hit would stress the crankshaft the most. Coincidence? We think not.

After carefully researching the different firing orders available to a V-8 engine, SoCal Diesel was the first to implement this "Alternative Firing Order" camshaft for the Duramax engine. In moving cylinders 3, 1 and 2 away from each other, we have significantly extended the abuse the crankshaft can withstand.

Swapping a few pins in the wiring harness will insure the ECM sends the injector signal to the correct cylinder. Wiring diagrams and instructions are included with every purchase.

  • Does not require any piston valve pockets.
  • Works well from idle past 3800 rpm.
  • Valve Lash .012/.012

The camshaft is an integral part of your engines breathing characteristics. The camshaft lobe profiles need to be carefully matched to the rest of the engine components in order to achieve maximum performance for any given application. We have designed profiles to meet many different applications that include dedicated Drag Racing and Sled Pulling.

Details

Shipping Information

  • Item Requires Shipping
  • 17.0 lbs.
  • W6.0000” x H6.0000” x L24.0000”
  • Free Shipping
